ISO | Dimensions (mm) | Weight | |||||
---|---|---|---|---|---|---|---|
open | shielded | sealed | GOST | d | D | B | (kg) |
580306 | 30 | 72 | 19 | 0.349 | |||
1580205 | 25 | 52 | 15 | 0.1 | |||
1580206 | 30 | 62 | 18 | 0.2 | |||
1580207 | 35 | 72 | 20 | 0.3 | |||
1580209 | 45 | 85 | 21 | 0.452 | |||
1580211 | 55 | 100 | 23 | 0.6 | |||
1680204 | 20 | 52 | 16/29 | 0.231 | |||
1680205 | 25 | 62 | 18/31 | 0.34 | |||
1680206 | 30 | 72 | 20/35 | 0.48 | |||
1680207 | 35 | 80 | 21/36 | 0.61 | |||
1680208 | 40 | 85 | 21/39 | 0.655 |
